Inconel 600 Daim Ntawv 1800mm * 1200mm * 3mm
Dec 18, 2020
Inconel 600 daim ntawv
1.Alloy 600 Tshuaj Tso Cai Rau Tshuaj
Khoom | Feem Raws Nyhav | |
N | Npib tsib xee | 72.0% |
Cr | Chromium | 14.0 - 17.0% |
Fe | Hlau | 6.0 - 10.0% |
C | Cov pa roj carbon | 0.05 - 1.50% |
Mn | Mangas Yaj | 1.0% Tshaj Loj |
Si | Txiag Silicon | 0,5% Max |
Cu | Tooj liab | 0,5% Max |
Al | Txhuas | 0.3% Max |
Cov Ti | Titanium | 0.3% Max |
B | Boron | 0.006% Tshaj Loj |
P | Phus Thas | 0.015% Max |
S | Tub Lauj | 0.015% Max |
Lub cev nqaij daim tawv
·Qhov ceev: .304 lb / in3
·Melting Khwv: 2470-2575 ° F
·Qhov Tshav Kub Tshwj Xeeb Btu / lb ° F: 0.11
·Poisson' s Piv: 0.29
Qhov sib npaug ntawm Cov Ntshav Ntshav
Kub,℉ | 70 | 1000 | 1200 | 1400 | 1600 | 1800 |
hauv / hauv ° F x 10-6 | - | 8.4 | 8.6 | 8.7 | 9.1 | 9.3 |
Thermal Kev Coj Ua
Kub,℉ | 70 | 1000 | 1200 | 1400 | 1600 | 1800 |
Btu-ft / ft2-hr- ° F | 8.6 | 13.2 | 14.3 | 13.0 | 16.7 | - |
Modulus ntawm Elasticity
Kub,℉ | 70 | 1000 | 1200 | 1400 | 1600 | 1800 |
Dynamic, psi x 106 | 30.0 | 25.6 | 24.5 | 23.6 | 22.2 | 20.4 |
Mechanical zog thiab cov khoom siv zog ntawm Alloy 600
Kub,℉ | 70 | 1000 | 1200 | 1400 | 1600 | 1800 |
0.2% Yield Zog, ksi | 37 | 28.5 | 26.5 | 17 | 9.0 | 4.0 |
Ulimate Tensile Muaj Zog, ksi | 93 | 84 | 65 | 27.5 | 15 | 7.5 |
Ntxim Ntxim Txawj Ua V-thais, ft-lbs | 45 | 47 | 39 | 46 | 80 | 118 |
2.Peb tau exported Inconel 600 daim ntawv rau koj siv
