TP304 TP304L Tube
Hom: Seamless, Welded
OD: 1/2 "-48"
Thickness: SCH5-SCHXXS
Ntev: 0-12M, Customized
Txheej Txheem: Kub / Cold Rolled, Kub ua haujlwm, Txias kos
TP304 TP304L Stainless hlau yeeb nkab piav qhia
SS 304 thiab 304L "18-8" stainless hlau yog cov qib feem ntau ntawm austenitic stainless hlau. Lawv muaj nuj nqis rau lawv zoo heev tiv thaiv atmospheric, dej tshiab, thiab acid / alkali corrosion. Lawv kuj muaj qhov zoo weldability thiab tsis yog -magnetic. Peb cov chaw tsim khoom muab TP304 thiab TP304L seamless thiab welded kav nyob rau hauv kub- dov los yog txias dov. Qhov ntau thiab tsawg ntawm 1/8 "mus rau 48" nyob rau hauv txoj kab uas hla, thiab peb tus neeg muag khoom kuj muaj cov kev pabcuam kev cai. Tiv tauj peb tam sim no kom luv nqi.
SS304 thiab 304l Txuj:
- ASTM A312 / ASME SA 312 (Seamless, Welded yeeb nkab)
- ASTM A269 / ASME SA269 (Seamless thiab Welded tubing)
- ASTM A213 / ASME SA213 Seamless raj
- ASTM A249 / ASME SA249 (Welded Tubes)
Cov yeeb nkab ASTM A312 TP 304 304l Specifications
| Specifications | ASTM A 312 / ASTM A213 / ASTM A269 / ASTM A249 / ASTM A 358 |
| Txuj | ASTM, ASME, API, EN 10216-5 / NACE MR0175 |
| Loj | 1/8 "NB rau 30" NB IN |
| ERW 304 Pipes | 1/2 "NB - 24" NB |
| EFW 304 Pipes | 6" NB - 100" NB |
| Tshwj xeeb hauv | Loj Diameter Loj |
| Teem caij | SCH 5, SCH 10, SCH 20, SCH 30, SCH 40, STD, SCH 80, XS, SCH 120, SCH 140, SCH 160, XXS |
| Hom | Seamless / ERW / Welded / Fabricated / LSAW Pipes |
| Daim ntawv | Round, Square, Rectangular, Hydraulic thiab lwm yam |
| Ntev | Ib qho Random, Ob Chav Random & Txiav Ntev. |
| Xaus | Plain End, Beveled kawg, Treaded |
| Ua kom tiav | 2B, No.4, No.1, No.8 Daim iav tiav |
| Kuaj |
|
| Peb Muab |
|
aisi 304 304l Tshuaj muaj pes tsawg leeg
| UNS | C | Mn | P | S | Si | Ni | Cr |
| S30400 | 0.080 max | max 2.00 Nws | 0.045 max | 0.030 max | max 1.00 Nws | 8.0–11.0 | 18.0–20.0 |
| S30403 | 0.030 max | max 2.00 Nws | 0.045 max | 0.030 max | max 1.00 Nws | 8.0–12.0 | 18.0–20.0 |
ASTM A312 TP 304 304L Mechanical Properties
| Mechanical Requirements | TIAB SA 304 | TP 304 L |
| Tensile zog, min. MPa [ksi] | 515 [75] | 485 [70] |
| Yield zog, min. MPa [ksi] | 205 [30] | 170 [25] |
| Elongation hauv 2", min.% | 35 | 35 |
| Brinell Hardness max. HBW | 192 | 192 |
| Vickers Hardness max. HV | 200 | 200 |
| Rockwell Hardness max. HRB | 90 | 90 |
ASME SA 312 TP 304 304L sib npaug
| QIB | UNS | EN | JIS | AFNOR | BS | WERKSTOFF NR. | GOST |
| ASTM A312 TP 304 | S30400 | X5CrNi18-10 | TIAB SA 304 | Z7CN18-09 | 304S31 | 1.4301 | 08Х18Н10 |
| ASTM A312 TP 304L | S30403 | X2CrNi18-9 | SUS 304 L | Z3CN18-10 | 304S11 | 1.4306/1.4307 | 03Х18Н11 |
ASTM A312 TP304 304L Seamless Pipes qhov ntau thiab tsawg
Loj: 6NB - 1200NB
OD: 1/8" - 12" NPS
Thickness: 0.6 - 12.7 hli
Length: Ib leeg, Ob Chav Random & Txiav Length
ASTM A312 TP304 304L ERW / Welded Pipes qhov ntau thiab tsawg
Loj: 1/8" - 36" NB, 1/4" - 36" OD
OD: 6.35 - 114.3 mm
Thickness: 0.8 - 12.7 hli
Ntev: mus txog 26 Meters
SUS 304 304L Stainless Hlau Yeeb Nkab Qhov Loj thiab Qhov Loj
| Nominal Pipe Loj | OD hauv (mm) sab nraud txoj kab uas hla |
Stainless hlau (ASME B36.19) | |||||
| DN | NPS | Sch5S hauv (mm) |
Sch10S hauv (mm) |
Sch40 S hauv (mm) |
Sch80S hauv (mm) |
Sch160S hauv (mm) |
|
| 6 | 1/8 | 0.405(10.3) | 0.049(1.24) | 0.068(1.73) | 0.095(2.41) | 0.124(3.15) | |
| 8 | 1/4 | 0.540(13.7) | 0.065(1.65) | 0.088(2.24) | 0.119 (3.02) | 0.145 (3.68) | |
| 10 | 3/8 | 0.675(17.1) | 0.065(1.65) | 0.091(2.31) | 0.126(3.20) | 0.158(4.01) | |
| 15 | 1/2 | 0.840(21.3) | 0.065(1.65) | 0.083(2.11) | 0.109(2.77) | 0.147(3.73) | 0.188(4.78) |
| 20 | 3/4 | 1.050(26.7) | 0.065(1.65) | 0.083(2.11) | 0.113(2.87) | 0.154(3.91) | 0.219(5.56) |
| 25 | 1 | 1.315(33.4) | 0.065(1.65) | 0.109(2.77) | 0.133 (3.38) | 0.179(4.55) | 0.250(6.35) |
| 32 | 1 1/4 | 1.660(42.2) | 0.065(1.65) | 0.109(2.77) | 0.140(3.56) | 0.191(4.85) | 0.250(6.35) |
| 40 | 1 1/2 | 1.900(48.3) | 0.065(1.65) | 0.109 (2.77) | 0.145(3.68) | 0.200(5.08) | 0.281(7.14) |
| 50 | 2 | 2.375(60.3) | 0.065(1.65) | 0.109(2.77) | 0.154(3.91) | 0.218(5.54) | 0.344(8.74) |
| 65 | 2 1/2 | 2.875(73) | 0.083(2.11) | 0.120(3.05) | 0.203 (5.16) | 0.276(7.01) | 0.375(9.52) |
| 80 | 3 | 3.500(88.9) | 0.083(2.11) | 0.120(3.05) | 0.216(5.49) | 0.300(7.62) | 0.438(11.13) |
| 90 | 3 1/2 | 4.000(101.6) | 0.083(2.11) | 0.120(3.05) | 0.226(5.74) | 0.318(8.08) | |
| 100 | 4 | 4.500(114.3) | 0.083(2.11) | 0.120(3.05) | 0.237(6.02) | 0.337(8.56) | 0.531(13.49) |
| 125 | 5 | 5.563(141.3) | 0.109(2.77) | 0.134(3.40) | 0.258(6.55) | 0.375(9.52) | 0.625(15.88) |
| 150 | 6 | 6.625(168.3) | 0.109(2.77) | 0.134(3.40) | 0.280(7.11) | 0.432(10.97) | 0.719(18.26) |
| 200 | 8 | 8.625(219.1) | 0.109(2.77) | 0.148(3.76) | 0.322(8.18) | 0.500(12.70) | |
| 250 | 10 | 10.750(273.1) | 0.134(3.40) | 0.165(4.19) | 0.365(9.27) | 0.500(12.70) | |
| 300 | 12 | 12.750(323.9) | 0.156(3.96) | 0.180(4.57) | 0.375(9.52) | 0.500(12.70) | |
| 350 | 14 | 14.000(355.6) | 0.156(3.96) | 0.188(4.78) | 0.375(9.52) | 0.500(12.70) | |
| 400 | 16 | 16.000(406.4) | 0.165(4.19) | 0.188(4.78) | 0.375(9.52) | 0.500(12.70) | |
| 450 | 18 | 18.000(457) | 0.165(4.19) | 0.188(4.78) | 0.375(9.52) | 0.500(12.70) | |
| 500 | 20 | 20.000(508) | 0.188(4.78) | 0.218(5.54) | 0.375(9.52) | 0.500(12.70) | |
| 550 | 22 | 22.000(559) | 0.188(4.78) | 0.218(5.54) | |||
| 600 | 24 | 24.000(610) | 0.218(5.54) | 0.250(6.35) | 0.375(9.52) | 0.500(12.70) | |
| 650 | 26 | 660 | |||||
| 700 | 28 | 711 | |||||
| 750 | 30 | 30.000(762) | 0.250(6.35) | 0.312(7.92) | |||
ASTM A312 stainless hlau Optimized version
| AISI | 304/304H/304L/304N/304LN |
| UNS | S30400 / S30409 / S30403 / S30451 / S30453 |
| Werkstoff Nr. | 1.4301 / 1.4306 / 1.4948 / 1.4311 |
TP304 / TP304L Seamless Welded yeeb nkab fabrication
- SS Seamless kav: Tsim los ntawm kev kos duab txias lossis kub dov txheej txheem yam tsis muaj vuam;
- SS Welded kav: Tsim siv cov txheej txheem vuam tshuab. Haum rau loj - cov kav dej, xws li ERW/EFW/SAW. High efficiency efficiency thiab tsawg tus nqi.
Qhov txawv ntawm 304 thiab 304L yeeb nkab yog dab tsi?
- Qhov sib txawv ntawm 304 thiab 304L yog lawv cov ntsiab lus carbon.
- 304 stainless hlau (C Tsawg dua lossis sib npaug li 0.08%) yog qhov ua rau muaj kev cuam tshuam ntawm intergranular corrosion thaum rhuab rau nws qhov kub thiab txias (kwv yees li 425℃- 815℃).
- 304L, los ntawm kev tswj cov pa roj carbon tsawg dua lossis sib npaug ntawm 0.03%, txo qhov tsim ntawm chromium carbide.
SS 304 304L Pipe Value Added Processing Services
- Kev kho cua sov, Annealing, Pickling
- Beveling
- Kev kuaj Ultrasonic
- Polishing
- Cov Kev Pab Cuam Kos Duab
Alloy 304 304l stainless hlau lwm tus neeg
HT PIPE yog ib tug zoo-paub stockist thiab exporter. Peb yog S30400 S30403 cov khoom siv nrog 15+ kev paub txog kev xa tawm. Peb tsis tsuas yog muab cov kav dej, phaj, puag ncig, tab sis kuj yog cov yeeb nkab fittings, flanges, thiab lwm yam. Tiv tauj peb kom paub ntau ntxiv thiab cov nqi dawb.
FAQ
Q: Txog stainless hlau 304l nqi ib kg?
A: Cov nqi ntawm $ 1 txog $ 3 ib kilogram, txawv nyob ntawm qhov loj, phab ntsa thickness, tus neeg muag khoom thiab lwm yam.
Q: Koj puas yog lub Hoobkas tsim khoom?
A: Yog. Factory xeem daim ntawv pov thawj yog xa nrog cov khoom.
Q: Kuv puas tuaj yeem muaj qee qhov qauv ua ntej xaj?
A: Yog lawm, tau kawg. kuaj dawb tab sis koj yuav tsum them tus xa khoom.
Q: Peb puas tuaj yeem tuaj xyuas koj lub tuam txhab?
A: Tau kawg. Peb zoo siab tau muaj koj nyob hauv Suav teb.
Q: Yam tsawg kawg nkaus Order Quantity yog dab tsi?
A: Tsis muaj MOQ.
Q: Cov nqe lus them nqi yog dab tsi?
A: T / T, L / C, Western Union, thiab lwm yam.
Q: Koj lub sijhawm xa khoom yog dab tsi?
A: Rau cov khoom lag luam, peb tuaj yeem xa cov khoom mus rau qhov chaw nres nkoj hauv 7 hnub tom qab tau txais koj cov nyiaj tso cia.
Rau lub sijhawm tsim khoom, nws feem ntau xav tau li 10 hnub - 35 hnub tom qab tau txais qhov tso nyiaj.
Q: Puas yog nws zoo rau kos kuv lub logo ntawm koj cov khoom?
A: Yog. OEM thiab ODM muaj rau peb.
Q: Peb Lub Tebchaws Exported
A: Indonesia, Is Nrias teb, Singapore, Malaysia, Iran, Russia, UAE, Chile, Nplog, Brazil, South Africa, thiab lwm yam
