Laminated Steel Phaj (tseem hu ua Bimetallic Steel Phaj) yog cov khoom siv sib xyaw, tsim los ntawm metallurgically sib txuas ob lossis ntau txheej ntawm cov ntawv hlau (xws li Carbon Steel & Stainless Steel, Alloy & Stainless Steel, Carbon Steel & Nickel Alloy).



• Txheej txheem: Lamination, Explosive Cladding, Kub Rolling Cladding, Txias Rolling Cladding.
• Qhov zoo: Muab cov txheej txheem tiv thaiv corrosion (piv txwv li, stainless hlau) nrog lub siab - lub zog txheej (piv txwv li, carbon hlau), ntsuas qhov ua tau zoo thiab tus nqi- ua tau zoo.
• Daim ntaub ntawv: Cov hlab ntsha tshuaj, cov chaw sab nrauv, cov khoom siv hluav taws xob nuclear.

Hu rau tam sim no

Txheej txheem lamination

Lub hauv paus ntsiab lus: Ua tiav atomic- qib kev sib raug zoo ntawm cov ntaub ntawv los ntawm kev sib xyaw ua ke ntawm cov yas deformation thiab diffusion tshwm sim ntawm qhov kub thiab txias.

Qhov zoo: Customizable qhov ntev thiab meej tswj tshaj cladding thickness.

Daim ntaub ntawv: Haum rau kev siv hauv cov khoom siv hluav taws xob, cov khoom siv hluav taws xob, thiab cov khoom zoo sib xws.



Explosive Bonding:

• Lub hauv paus ntsiab lus: Siv lub siab tsim los ntawm kev tawg ntawm cov khoom tawg kom ua tiav cov hlau nplaum ntawm cov khoom txheej.
• Bonding Strength: Ntau dua lossis sib npaug li 200 MPa
• Thickness Range: 2.0mm - 100mm (tag nrho)
• Uniformity: Siab



Roll Bonding (Cov Txheej Txheem Kub / Cold Roll Bonding Process)

• Lub hauv paus ntsiab lus: Ob lossis ntau dua cov ntawv hlau tau muab tso rau hauv lub qhov cub cua sov thiab sib koom ua ke los ntawm siab -siab dov ntawm qhov kub siab.
• Scope ntawm daim ntawv thov: Haum rau nyias cladding txheej (Ntau tshaj los yog sib npaug rau 0.5 hli).
• Kev Ua Tau Zoo: Siab.
• Daim ntaub ntawv: Haum rau cov kav dej, cov hlab ntsha siab, thiab cov khoom siv tshuaj.





Common laminated steel phaj ua ke muaj xws li:

• Carbon hlau + Stainless hlau
• Carbon Steel + Duplex Stainless Hlau
• Carbon hlau + Nickel Alloy
• Tsawg Alloy Steel + Titanium



Common Laminated Steel Phaj Nqe

Khoom siv sib xyaw	Thickness Ntau	Tus nqi kwv yees 2026
Carbon Steel + 304 Clad	6-50 hli	$1,500–$2,800/ton
Carbon Steel + 316L Clad	8-60 hli	$2,200–$3,900/ton
Carbon Steel + Duplex 2205	10-80 hli	$3,500–$5,500/ton
Carbon Steel + Inconel 625	10-60 hli	$5,500–$8,500/ton
Titanium Clad Steel Phaj	8-40 mm	$6,000–$12,000/ton



Cov txheej txheem lamination ntawmA240 SS daim hlauyog ib txoj kev uas muaj kev sib txuas ntawm ntau txheej hlau.Kub Rolled Stainless Hlau Phajuas undergo cov txheej txheem lamination feem ntau muaj ntau yam ntawm cov yam ntxwv uas ua rau lawv xav tau ntau yam kev lag luam.



Cov txheej txheem rau lamination cuam tshuam nrog kev tsim cov khoom sib xyaw ua ke los ntawm kev sib txuas ob lossis ntau duaCold Rolled Alloy Phajua ke. Qhov kawg tshwm sim yog cov phaj hlau uas muaj lub zog ntau dua - rau - qhov hnyav piv, nce durability, thiab txhim kho corrosion kuj.



Muaj ntau yam txheej txheem uas yuav siv tau nyob rau hauv cov txheej txheem lamination ntawmStainless hlau 316 daim hlau. Cov txheej txheem no muaj xws li kub dov, txias dov, kub nias, thiab txias nias. Kub dov yuav ua rau cua sovSS 316L HR phajmus rau qhov ntsuas kub thiab tom qab ntawd khiav lawv los ntawm ib khub ntawm cov menyuam. Txias dov, ntawm qhov tod tes, koom nrog kev siv chav tsev kub steel daim hlau thiab kev siv lub siab los khi lawv ua ke.



Kub thiab txias nias, lub sijhawm no, koom nrog kev siv cov tshuab tshwj xeeb uas ua rau muaj kev kub ntxhov siab ntawmNickel Alloy Phajlos khi lawv ua ke. Nyob ntawm seb qhov xav tau thickness ntawm cov khoom siv sib xyaw, cov phaj hlau tuaj yeem laminated hauv ntau txheej siv cov txheej txheem ntau yam.



Ib qho ntawm qhov zoo ntawm cov txheej txheem lamination ntawmASTM B575 Hastelloy Phajyog tias nws tuaj yeem tsim cov khoom sib xyaw nrog cov khoom tshwj xeeb kom tau raws li qhov xav tau ntawm cov ntawv thov tshwj xeeb. Piv txwv li, steel phaj siv hauv kev tsim kho kev lag luam yuav xav tau lub zog siab thiab ua haujlwm ntev kom tiv taus huab cua hnyav, whereasAlloy A387 CR Phajsiv nyob rau hauv kev lag luam tsheb yuav xav tau zoo heev corrosion kuj mus ntev.



Cov txheej txheem lamination ntawmKub Rolled Carbon Steel Phajyog cov txheej txheem tshwj xeeb thiab kev tshaj lij uas ua tau zoo tshaj - cov ntawv hlau zoo nrog cov yam ntxwv tshwj xeeb. Cov ntaub ntawv sib xyaw no tau siv dav hauv ntau yam kev lag luam, suav nrog kev tsim kho, tsheb, thiab aerospace, thiab lwm yam. Yog li ntawd, cov txheej txheem lamination tau dhau los ua cov cuab yeej tseem ceeb rau kev tsim cov khoom siv steel siab - ua tau raws li cov kev xav tau ntawm cov neeg niaj hnub no.





Yuav Laminated Steel Phaj Qhia Qhia:

• Cladding Rate: Paub meej qhov tsawg kawg nkaus thickness ntawm cladding txheej (piv txwv li, 15%, 20%, los yog 30%).
• Bonding Defect Inspection: Yuav tsum xeem dhau Ultrasonic Test (UT) kom paub meej tias tsis muaj kev cuam tshuam cuam tshuam.
• Surface Finish: 2B, BA, lossis No.1 tiav raws li xav tau.
• Material Traceability: Muab daim ntawv pov thawj khoom qub (MTC)





Q: Dab tsi yog Lamination Txheej Txheem ntawm Hlau Phaj?

A: Hlau phaj lamination, kuj hu uaclad phaj manufacturinglos yogsteel phaj sib txuas, yog txheej txheem metallurgical uas ob lub hlau sib txawv tau koom ua ke mus tas li los tsim ib lub phaj sib xyaw.



Q: Puas muaj qhov tsawg kawg nkaus txiav txim kom muaj nuj nqis (MOQ) rau kev cai laminated steel daim hlau?

A: Feem ntau, MOQ yog 100KG. Rau cov ntaub ntawv txheem (xws li 304/316L + Q235), peb muab ceev ceev hauv 7-30 hnub ua haujlwm.



Q: Puas yog laminated composite steel daim hlau puas cuam tshuam rau delamination?

A: Raws li ib txwm muaj, delamination tsis tshwm sim. Txawm li cas los xij, yog tias nplai lossis roj paug muaj nyob ntawm qhov sib txuas sib txuas, qhov zoo ntawm daim ntawv cog lus yuav raug cuam tshuam.



Q: Lub laminated steel phaj puas tuaj yeem welded?

A: Yog. Cov kev sib txuas sib txuas yog metallurgical fusion, uas muaj cov weldability zoo heev.



Q: Qhov txawv ntawm Laminated Steel Phaj thiab Clad Plate yog dab tsi?

A: Lawv yog cov tseem ceeb tib yam khoom. "Laminated" qhia txog cov txheej txheem tsim khoom, thaum "Clad" qhia txog cov txheej txheem txheej txheej.



Q: Lub hom phiaj ntawm steel phaj lamination yog dab tsi?

A: Hlau phaj lamination sib xyaw ua ke lub zog ntawm cov hlau nrog corrosion kuj ntawm stainless hlau los yog alloy cov ntaub ntawv ntawm tus nqi qis.



Daim Ntawv Thov Case 1: Chemical Processing Plant

Kev daws: 316L / Carbon Steel Laminated Hlau Phaj,Piv rau cov khoom tsis muaj steel hlau, cov khoom siv ntawm cov phaj clad yog txo los ntawm 40%.



Daim ntawv thov Case 2: Chaw nres tsheb fais fab boiler

Kev daws: 310S / Carbon Steel Laminated Phaj,Txhim kho cov teeb meem tawg tau zoo los ntawm kev nthuav dav thermal thaum lub sijhawm ua haujlwm tsis sib xws.
