ASTM B474 B619 B626 UNS N10276 Hastelloy C-276 Welded Yeeb Nkab Tube
Hom: Seamless, Welded
OD: 1/2 "-48"
Thickness: SCH5-SCHXXS
Ntev: 0-12M, Customized
Txheej Txheem: Kub / Cold Rolled, Kub ua haujlwm, Txias kos
Hastelloy C276 Pipes Tubes Nqe lus piav qhia
Peb muab cov Hastelloy C276 Welded Tubes nyob rau hauv thoob ntiaj teb thiab lub teb chaws zoo ntawm cov qauv ntawm tus nqi ntawm tus nqi - zoo rau peb patrons. Raws li cov chaw tsim khoom, cov khoom lag luam, cov khoom lag luam thiab cov xa tawm, peb muab cov Alloy C276 UNS N10276 Cov Yeeb Nkab thiab Tubes hauv kev cai -ua qhov ntau thiab tuab raws li qhov xav tau tiag tiag ntawm peb cov neeg siv khoom.
ASTM B474 B619 B626 Hastelloy C276 ERW Yeeb Nkab Exporter, Alloy C276 EFW Welded Tubing Leading Manufacturers
Hastelloy C276 UNS N10276 welded Pipes Txheem:
- ASTM B619 / B619M - Txuj Specification rau Welded Nickel thiab Nickel -Cobalt Alloy Yeeb Nkab
- ASTM B626 / B626M - Txuj Specification rau Welded Nickel thiab Nickel -Cobalt Alloy Tube
- ASTM B474 / B474M - Txuj Specification rau Hluav Taws Xob Fusion Welded Nickel thiab Nickel Alloy Yeeb Nkab
Hastelloy C-276 Khoom Khoom
Hastelloy C276 yog austenitic nickel-molybdenum-chromium alloy nrog me me ntxiv ntawm tungsten. Nickel alloy UNS N10276 siab molybdenum thiab chromium cov ntsiab lus, ua ke nrog kev sib ntxiv ntawm tungsten, muab kev tiv thaiv zoo heev rau chloride kev nyuaj siab corrosion cracking, pitting, crevice corrosion, thiab dav dav corrosion. Hastelloy 2.4819 tuaj yeem ua haujlwm hauv qhov chaw oxidizing txog 1900℃F (1038 degree). Cov ntsiab lus tsis tshua muaj carbon ntawm C-276 npib tsib xee alloy tso cai rau nws siv rau hauv cov xwm txheej zoo li-welded.
ASTM B619 / B626 / B474 Hastelloy C276 Yeeb Nkab & Tubes Specification
- Txuj: ASTM, ASME B622, B619, B775, B516, B626
- Hom: Seamless / ERW / Welded / Fabricated / LSAW Pipes
- Daim ntawv: Round, Square, Rectangular, Hydraulic thiab lwm yam.
- Length: Ib qho Random, Ob Chav Ranidom & Txiav Length
- Xaus: Plain End, Bevelled End, Treaded
-
MTC Certificate:EN 10204 3.1 thiab 3.2
-
Kev xeem: ASTM E38, E10, E18, E8, E140, E1473
Hastelloy C276 Welded Pipes Loj
- ASTM B626: specification npog raj 1/8 txog 31/2 nyob rau hauv.
- ASTM B619: specifications npog cov yeeb nkab hauv Teem caij 5S, 10S, 40S, thiab 80S txog 8 in. nominal yeeb nkab loj thiab loj raws li tau teev tseg hauv ANSI B36.19
Hastelloy C276 UNS N10276 welded Pipes & Tubes Tshuaj Chemical Composition
|
Ni |
Bal |
|
C |
0.01 max |
|
Mn |
1.0 max |
|
Co |
2.5 max |
|
S |
0.03 max |
|
Si |
0.08 max |
|
Cr |
14.5 – 16.5 |
|
Mo |
15 – 17 |
|
Fe |
4 – 7 |
|
W |
3 – 4.5 |
|
v |
0.35 max |
|
P |
0.04 max |
Hastelloy C276 welded Pipes & Tubing Mechanical & Physical Properties
|
Qhov ntom |
8.89g 3 |
|
Melting Point |
1370℃(2500℃F) |
|
Tensile zog |
Psi - 1,15,000, MPa - 790 |
|
Yield zog (0.2% Offset) |
Psi - 52,000, MPa - 355 |
|
Elongation |
40 % |
|
Hardness (Brinell) |
- |
Hastelloy C276 welded Pipes & Tubing sib npaug qib
|
STANDARD |
WERKSTOFF NR. |
UNS |
JIS |
LOSSIS |
GOST |
AFNOR |
EN |
|
Hastelloy C276 |
2.4819 |
N10276 |
wb 0276 |
ЭП760 |
ХН65МВУ |
- |
NiMo16Cr15W |
Kev ntsuas siab ntawm C276 Alloy EFW Yeeb Nkab
| cev OD (hauv.) |
Phab ntsa Thickness ntawm cov yeeb nkab (inch) | |||||||
|---|---|---|---|---|---|---|---|---|
| 0.028 | 0.035 | 0.049 | 0.065 | 0.083 | 0.095 | 0.109 | 0.120 | |
| Ua haujlwm siab (psig) | ||||||||
| 1/8 | 7900 | 10100 | ||||||
| 1/4 | 3700 | 4800 | 7000 | 9500 | ||||
| 5/16 | 3700 | 5400 | 7300 | |||||
| 3/8 | 3100 | 4400 | 6100 | |||||
| 1/2 | 2300 | 3200 | 4400 | |||||
| 3/4 | 2200 | 3000 | 4000 | 4600 | ||||
| 1 | 2200 | 2900 | 3400 | 3900 | 4300 | |||
Hastelloy C276 ERW Steel Yeeb Nkab Fabrications
- Txheej Txheem: ERW, EFW, Welded thiab lwm yam.
- Daim ntawv: Hydraulic, Round, Chev, Ncaj thiab lwm yam.
- Txheej Txheem: Precision Rolled, Txias thiab Kub Tsim thiab lwm yam.
- Finish: Polished, Annealing, Ci, Pickling thiab lwm yam.
ASTM B626 Hastelloy C276 welded raj siv cov txheej txheem vuam tsis siv neeg, tshem tawm qhov xav tau rau cov hlau muab tub lim. Hastelloy ERW yeeb nkab tuaj yeem muab cov tshuaj annealed. Nickel Alloy n10276 yog cov tshuaj kho cua sov ntawm 1121℃(2050℃F) thiab tom qab ntawd sai sai.
ASTM B626 UNS N10276 Welded Yeeb Nkab Test
- Tensile, yield zog, thiab elongation xeem
- Kev xeem tshuaj muaj pes tsawg leeg
- Eddy tam sim no thiab flattening xeem
- Kev ntsuas pneumatic thiab hydrostatic siab
Hastelloy C276 Welded Yeeb Nkab Nqe Sau
Yuav Hastelloy C276 Round Pipe, Nickel Alloy C276 welded kav hauv ntau qhov ntau thiab tsawg
| Alloy C-276 Welded (Pib) | 36.87 Nws |
|
Nickel Hastelloy C-276 Alloy Yeeb Nkab 2.375 X 2.067 X 0.154 Mm |
20.83 Nws |
| 2inch Nb Sch80 C276 Yeeb Nkab | 49.7 Nws |
Lub teb chaws Peb xa tuaj rau
Ukraine, United Kingdom, Lebanon, Angola, Kaus Lim Qab Teb, Norway, Romania, Libya, Chile, Sweden, Serbia, Bolivia, Qaib ntxhw, Puerto Rico, Bahrain, Nigeria, Nyiv, Jordan, Poland, United Arab Emirates, Trinidad & Tobago, Tunisia, Netherlands, Belarus, Nigeria, Lithuania, C Republic, Russia, Brazil, Taiwan, Tibet, Qatar, Gambia, Venezuela, Thaib, Saudi Arabia, Kazakhstan, Ecuador, Iran, Switzerland, Poland, Tuam Tshoj, Australia, Gabon, Kuwait, Iran, Finland, Namibia, Philippines, Hungary, Nepal, Portugal, Croatia, Yemen, Belgium, Canada, Pakistan, Mongolia, Mexico, Estonia, Israel, Zimbabwe, Costa Rica, Slovakia, Peru, Mexico, Chile, Ireland, Oman, Bangladesh, Morocco, United States, Sri Lanka, Lub teb chaws Yelemees, Indonesia, Azerbaijan, Fabkis, Macau, Colombia, Denmark, Hong Kong, Malaysia, Bulgaria, Kenya, Nyab Laj, Tim lyiv teb chaws, Ltalis, Tim Nkij teb chaws, Algeria, Ghana, New Zealand, Singapore, Is Nrias teb, Iraq, Afghanistan, Bhutan, South Africa, Austria, Argentina, Spain
ASTM B626 Hastelloy Welded Tubing & UNS N06022 ERW Tube Chaw tsim khoom hauv Suav teb
FAQ
Q: TxogHastelloy C276 Welded yeeb nkabtus nqi?
Q: Koj lub sijhawm khoom xa tuaj ntev npaum li cas?
Q: Puas muaj Kev Pabcuam Qauv?
Q: Yam tsawg kawg nkaus Order Quantity yog dab tsi?
Q: Yuav ntim cov khoom li cas?
Q: Lub teb chaws xa tawm
Q: Peb puas tuaj yeem tuaj xyuas koj lub Hoobkas?
A: Tau kawg, koj ib txwm txais tos!
Q: Puas yog nws zoo rau kos kuv lub logo ntawm cov khoom?
A: Yog. Peb yog OEM thiab ODM, Kev them nyiaj yug Customized
