Nickel 200 Cov Yeeb Nkab
1. Tus Qauv: Astm B161 / ASME SB 161, B163 / ASME SB 163, ASTM B474 / ASME SB 474
2. Qib: Tsis Raws N02200, NI200, 2.4066
3. Hom: Nickel seamless thiab Welded Yeeb Nkab
4. Xaus: Beveled Kawg, Plain Kawg
Nickel 200 Cov Yeeb NkabYog tsim los ntawm cov neeg ntshiab uas muaj cov ntsiab lus npib tsib xee li 99%, thiab tseem muaj cov hlau, manganese, silicon, roj carbon, thiab tooj. NI200 kev ua kom muaj zog tiv taus kom muaj zog alkalis. Npib tsib xee 200 ntom yog 8.9 g / cm³; Nickel 200 melting point yog 1446℃(2635℃f); npib tsib xee 200 hardness yog 70 brinell hardness. ASTM B161 UNSICS N02200 cov khoom siv kuj muaj cov thermal zoo heev thiab hluav taws xob conductivity. Peb cov chaw muag khoom muab seamless lossis welded Nickel 200 tubing.Tiv Tauj Pebrau kev cai ntev thiab tus nqi.
Lub Hoobkas Nickel 200 Cov Khoom Siv Hluav Taws Xob, Astm B161 tsis yog N02200 tubing cov neeg muag khoom hauv Suav teb
NI200 Nickel 200 Khoom Siv Khoom:
- Tiv taus rau alkali corrosion
- Ruaj khov hauv tsis - oxidizing acids xws li hydrochloric acid thiab phosphoric acid
- Saib xyuas lub zog hauv ib puag ncig cryogenic (piv txwv li, kua oxygen, ua kua nitrogen tej yam kev mob)
- Cov txheej txheem ntawm kev siv tsev, khoov, stamping, thiab lwm txoj kev sib
- Tsis - sib nqus
Nickel 200 Raj spec daim duab qhia
| Lub hom phiaj | ASTM B 161 / ASME SB161, B 163/11 / SB 725, B 75 / SB 751, B 829 / SB 829, DB 829, DIN 8251, ISO 6207 |
| Qhov tuab | 0.3 hli - 50 hli, Sch10, Sch10, Sch 40, Sche, Sch XXS, SCH Xs |
| Txheej hauv lub taub | 6.00 mm od li 914.4 mm od, ntau thiab tsawg txog 24 "nb |
| Teem caij | SCH5, SCH10, SCH40, STD, SCH80, SCH160 |
| Ntaus | Seamless / Erw / Welded / Fabricated / CDW |
| Puab | Puag ncig cov hlab, cov raj kab plaub, cov leeg roj, "u" duab, lauj kaub ncuav mog qab zib chev, hlab ntsha hydraulic |
| Qho ntev | Ib leeg random, ob npaug random & xav tau ntev |
| Qhov kawg | Dawb kawg, beveled kawg, tsuj las. |
| Kev cim | Txheem, qib kawm, od, tuab, ntev, tshav kub tsis tau (lossis raws li tus neeg siv khoom thov.) |
Nickel 200 Tshuaj Raug Tshuaj
| Nickel 200 | Ni | C | Mn | Si | Zaum fe | S | CU | S | Zaum fe |
| 99.0 min | 0.15 Max | 0.35 max | 0.35% max | 0.4 max | 0.01 max | 0.25 max | 0.01% max | 0.40% max |
Nickel 200 tub ceev cov khoom siv
| Tawm Zog (0.2% offset) | Lub zog tensile | Elongation |
| Psi - 21500}, mpa- 148 | Psi - 67000}, mpa- 462 | 45% |
Nickel 200 sib npaug
| Lub hom phiaj | Tsis yog | Werkstoff NR. | Ib tug kaum | En | JIS | Bs | Gost |
| Nickel 200 | N02200 | 2.4066 | N-100M | Ni 99.2 | NW 2200 | Na 11 | НП-2 |
Nickel 200 Yeeb Nkab Ua Haujlwm Kub
Nickel 200 feem ntau haum rau siv nyob rau hauv qab no 600℃f (315 degree). Thaum ntau dua kub, yuav tshwm sim.
Qhov sib txawv ntawm Nickel 200 thiab 201
- Nickel 200 (Tsis Yog N02200): Tshaj Tawm Cov Ntsiab Lus Carbon 0.15%, kev ua haujlwm kub txog li 600℃f (315 degree)
- Nickel 201 (unsal n02201): Ntau Tshaj Plaws Cov Ntsiab Lus 0.02%, kev ua haujlwm kub txog li 1250℃f (677 degree)
ni 200 Fabrication cov ntaub ntawv
1. Npib 200 Annealing:
Nickel 200 alloy annaling kub feem ntau yog li ntawm kwv yees li 1300℃f rau 1700℃f (705℃rau 925 degree).
2. Nickel 200 machinability:
Nickel 200 yog kev lag luam npib tsib xee, uas yog softer thiab muaj cov khoom ua tau zoo dua qub.
3. Vuam Nickel 200:
Nickel 200 Cov Yeeb Nkab Tau Pom Zoo Siv Roj Tungsten Arc Vuam (Gmaw / Mig), Roj Hlau), Roj Vuam, thiab lwm yam. Lub vuam cov khoom tuaj yeem xaiv tau Erni-1
Nickel Alloy 200 Kav Dej & Tubes Exporters
HT Peb yog Ni200 cov khoom siv rau cov chaw muag khoom nrog 15+ export kev. Peb tsis tsuas yog muab cov kav dej nkaus xwb, daim hlau, cov kab ncig, tab sis kuj cov yeeb nkab fittings, flanges, thiab lwm yam tuaj yeem tiv tauj peb thiab cov nqi pub dawb.
Cov FAQ
Q: Hais txog ntawm Nickel 200 tubing nqi?
A: Cov nqi los ntawm Ranges $ 15 txog $ 25 rau ib phaus, sib txawv nyob ntawm qhov loj me, cov phab ntsa tuab, tus xa khoom tuab si thiab lwm yam.
Q: Koj puas yog lub Hoobkas khoom siv?
A: Yog. Lub Hoobkas xeem ntawv daim ntawv pov thawj yog xa nrog cov khoom.
Q: Kuv puas tuaj yeem muaj qee qhov qauv ua ntej xaj?
A: Yog lawm, tau kawg. Cov qauv yog pub dawb tab sis koj yuav tsum them tus neeg xa xov.
Q: Peb puas tuaj yeem mus saib koj lub tuam txhab?
A: Tau kawg. Peb yuav tau txais kev hwm kom muaj koj nyob ntawm Suav.
Q: Qhov kev txiav txim yam tsawg kawg nkaus?
A: Tsis muaj MOQ.
Q: Cov ntsiab lus them nqi yog dab tsi?
A: T / T, L / C, Western Union, thiab lwm yam.
Q: Koj lub sijhawm xa khoom dab tsi?
A: Rau cov khoom lag luam, peb tuaj yeem xa cov khoom lag luam rau chaw nres nkoj chaw nres nkoj tsis pub dhau 7 hnub tom qab tau txais koj qhov tso nyiaj.
Rau lub sijhawm ntau lawm, nws feem ntau xav tau txog 10 - 35} hnub tom qab tau txais qhov tso nyiaj.
Q: Nws puas ua li cas los kos kuv lub logo ntawm koj cov khoom?
A: Yog. OEM thiab ODM muaj rau peb.
Q: Peb lub tebchaws xa tawm
A: Indonesia, Is Nrias teb, Singapore, Malaysia, UAS, Russia, UAE, Tebchaws Asmeskas, Brazil, East Africa, thiab lwm yam
