ASTM A240 S32750 Hlau Phaj 1mm Thickness Sheet
Hom: Phaj, Sheet, Sawb, Coil
Ntev: 0-12m
Dav: 0-2500mm
Thickness: 0.3-1200 hli
Txheej Txheem: Kub / Cold Rolled
Nto: 1,2D,2B,3,4,6,7
ASTM A240 S32750 Hlau Phaj Daim Ntawv Qhia
ASTM A240 S32750 steel ntawvmuaj nyob rau hauv ntau qhov thicknesses thiab qhov ntau thiab tsawg . 1mm yog thinnest txias-rolled sheet hlau peb tus neeg muag khoom tuaj yeem muab tau. Tau kawg, peb kuj muab cov ntawv kub - dov, nrog rau cov phaj tuab, thiab lwm yam. Nws yog feem ntau siv nyob rau hauv ntau yam lag luam, tshwj xeeb tshaj yog nyob rau hauv cov roj thiab roj sector, qhov twg nws yog siv rau subsea khoom, platforms, thiab pipelines. Cov kev lag luam tshuaj thiab petrochemical kuj tseem siv 2507 duplex stainless hlau rau cov tso tsheb hlau luam, cov khoom siv hluav taws xob, thiab cov hlab ntsha siab.
Duplex 2507 Stainless Steel Sheet kuj tseem siv rau hauv kev lag luam pulp thiab ntawv, qhov twg nws tau siv rau cov khoom siv tshuaj tua kab mob thiab cov khoom siv tshuaj dawb. Nws yog cov khoom siv nrov xaiv rau cov nroj tsuag desalination vim nws qhov siab tiv taus chloride kev nyuaj siab corrosion cracking. Lwm cov kev lag luam uas siv S32750 steel ntawv muaj xws li aerospace, kev tsim kho, thiab marine engineering, rau npe rau ob peb tug.
SDSS 2507 Phaj Sheet Dimensions
- Kub- dov daim hlau:
Thickness ntawm 3.0 hli - 200 hli.
Dav muaj xws li 1000mm, 1219mm (48 nti), 1500mm, 1800mm, 2000mm, thiab lwm yam.
- Txias-cov ntawv yob:
Thickness ntawm 0.4 hli - 0.5 hli, mus txog 6.0 hli.
Dav muaj xws li 600mm, 1000mm, 1219mm (48 nti), 1500mm, thiab lwm yam.
ASTM A240 Uns S32750 Khoom Specification
|
Txuj |
ASTM, AISI, AMS, MLS, EN, JIS, DIN, GOST |
|
Thickness |
1.2-100 hli |
|
Dav |
1000-2500 hli |
|
Ntev |
1000-12000mm |
|
Nto |
2B, No.3, No.4, HL, BA, 8K |
|
Cov txheej txheem tsim khoom |
Kub dov, txias dov |
|
Duplex Hlau |
SAF 2205/UNS S31803, SAF 2507/UNS S32750, S32760, S32205, S32250, N08904/1.4539, 254SMO/S31254/1.4574 |
|
Ntim |
Bubble hnab thiab plywood pallet lossis raws li cov neeg siv khoom xav tau. |
|
Lub sij hawm xa tuaj |
10-35 hnub nyob ntawm seb muaj pes tsawg |
|
Cov nqe lus them nqi |
T/T |
|
Kev xa khoom |
FOB Tianjin / Shanghai, CIF, CFR, thiab lwm yam |
|
Daim ntawv thov |
Petroleum/Power/Chemical/Gas/Metallurgy/Shipbuilding/Construction, thiab lwm yam |
| Daim ntawv pov thawj |
|
Factory Super Duplex 2507 Sheet, Duplex SS S32750 Cov khoom lag luam, tiv tauj peb rau cov ntaub ntawv loj thiab luv nqi.
Dab tsi yog Super Duplex S32750 Khoom?
Stainless hlau yog S32750, tseem hu ua Saf 2507. Cov qib no muaj kev tiv thaiv corrosion, tshwj xeeb tshaj yog tiv thaiv dej hiav txwv thiab cov kua qaub. Nws yog ib qho super duplex stainless hlau uas muaj ob qho tib si austenitic thiab ferritic microstructures, muab nws qhov sib xyaw ua ke ntawm lub zog thiab kev tiv thaiv corrosion.
- Resistant chloride kev nyuaj siab corrosion cracking
- Siab zog
- Resistant rau pitting thiab crevice corrosion
- Haum rau kub hauv qab 600℃F (316 degree)
- Tsawg coefficient ntawm thermal expansion
- Zoo weldability thiab machinability
ASME SA 240 UNS S32750 Chemical Composition
| Cr | Ni | Mo | C | Mn | P | S | Si | N |
| 24.0-26.0 | 6.0-8.0 | 3.0-5.0 | 0.03 | 1.2 | 0.035 | 0.02 | 0.8 | 0.24-0.32 |
SA 240 UNS S32750 Mechanical Properties:
- Tensile zog: 800-1000 MPa
- Yield zog: 550 MPa min
- Elongation: 15% min
- Hardness: 250 max HB
Alloy 2507 Stainless hlau lub cev muaj zog
| Qib | Melting Point (zeeg) | Melting Point (° F) | Qhov ceev (g / cm3) | Qhov ceev (lb / hauv 3) |
| S32750 | 1350 | 2460 | 7.8 | 0.281 |
ASTM A240 Txuj
ASTM A240 yog tus qauv tshwj xeeb rau chromium thiab chromium-nickel stainless hlau phaj, ntawv, thiab sawb rau cov hlab ntsha siab thiab rau kev siv dav dav. Cov kev qhia tshwj xeeb suav nrog qib 304, 304L, 316, thiab 316L, 904L, 254SMO, 2205, 2507 thiab lwm yam.
ASTM A240 UNS S32750 sib npaug
| UNS | EN | WN.R | EN | AFNOR | SS |
| S32750 | X2CrNiMoN25-7-4 | TS EN 1.4410 | 022Cr25Ni7Mo4N | Z3 CN 25.06 Az | 2328 |
SAF 2507 Super DuplexKev tsim khoom
- Kub sib sauyog ua nyob rau hauv qhov kub ntawm 1875 ° F txog 2250 ° F.
- Txias txoj kevyog ua tau, tab sis me ntsis nyuaj.
- Kev kho cua sov: Alloy 2507 yuav tsum tau muab tshuaj annealing thiab quenching tom qab ob qho tib si kub thiab txias sib sau. Qhov kub yuav tsum yog tsawg kawg yog 1925 ° F, ua raws li huab cua ceev los yog dej quenching.
Peb muab kev kuaj puas tsuaj thiab tsis yog -kev kuaj kev puas tsuaj:
- Kev ntsuas cov cuab yeej cuab tam, xws li tensile, dabtsi yog khoov, thiab cuam tshuam
- Tshuaj ntsuam xyuas -spectral tsom xam thiab PMI kuaj
- Kev sim hardness
- Pitting corrosion susceptibility xeem
- X-kev soj ntsuam kab hluav taws xob
- Eddy kev sim tam sim no
- Kev ntsuas hydrostatic siab
- Intergranular corrosion nrhiav kom tau
- Kev ntsuam xyuas metallographic
Tuam Tshoj Duplex Stainless Hlau Chaw tsim tshuaj paus
HT PIPE yog ib tug zoo -paub stockist thiab exporter. Peb yog cov khoom siv 2507tus xa khoom nrog 15+ kev xa tawm. Peb tsis tsuas yog muab cov kav dej, phaj, puag ncig, tab sis kuj yog cov yeeb nkab fittings, flanges, thiab lwm yam. Tiv tauj peb kom paub ntau ntxiv thiab cov nqi dawb.
FAQ
Q: Txog super duplex 2507 nqe?
A: Tus nqi ntawm $ 1 txog $ 5 ib kilogram, txawv nyob ntawm qhov loj me, phab ntsa thickness, tus neeg muag khoom thiab lwm yam.
Q: Koj puas yog lub Hoobkas tsim khoom?
A: Yog. Factory xeem daim ntawv pov thawj yog xa nrog cov khoom.
Q: Kuv puas tuaj yeem muaj qee qhov qauv ua ntej xaj?
A: Yog lawm, tau kawg. kuaj dawb tab sis koj yuav tsum them tus xa khoom.
Q: Peb puas tuaj yeem tuaj xyuas koj lub tuam txhab?
A: Tau kawg. Peb zoo siab tau muaj koj nyob hauv Suav teb.
Q: Yam tsawg kawg nkaus Order Quantity yog dab tsi?
A: Tsis muaj MOQ.
Q: Cov nqe lus them nqi yog dab tsi?
A: T / T, L / C, Western Union, thiab lwm yam.
Q: Koj lub sijhawm xa khoom yog dab tsi?
A: Rau cov khoom lag luam, peb tuaj yeem xa cov khoom mus rau qhov chaw nres nkoj hauv 7 hnub tom qab tau txais koj cov nyiaj tso cia.
Rau lub sijhawm tsim khoom, nws feem ntau xav tau 10 hnub - 35 hnub tom qab tau txais qhov tso nyiaj.
Q: Puas yog nws zoo rau kos kuv lub logo ntawm koj cov khoom?
A: Yog. OEM thiab ODM muaj rau peb.
Q: Peb Lub Tebchaws Exported
A: Indonesia, Is Nrias teb, Singapore, Malaysia, Iran, Russia, UAE, Chile, Nplog, Brazil, South Africa, thiab lwm yam
Cim npe nrov: ASTM A240 S32750 Steel Phaj 1mm Thickness Sheet, Tuam Tshoj, manufacturers, hoobkas, nqe, customized
