Txias Rolled Hastelloy C276 Nickle Alloy Sheet Phaj Nqe Hoobkas
Hom: Phaj, Sheet, Sawb, Coil
Ntev: 0-12m
Dav: 0-2500mm
Thickness: 0.3-1200 hli
Txheej Txheem: Kub / Cold Rolled
Nto: 1,2D,2B,3,4,6,7
Zhengzhou Huitong Pipeline Equipment Co., Ltd. yog ib qho ntawm cov tuam txhab ua lag luam thiab cov neeg muag khoom ntawm kub dov hastelloy c276 nickle alloy ntawv phaj nqe Hoobkas hauv Suav teb. Peb sov siab txais tos koj mus yuav peb cov khaub thuas dov hastelloy c276 nickle alloy ntawv phaj nqe Hoobkas. Peb lub Hoobkas kuj lees txais cov kev txiav txim customized. Thov pub dawb kom txaus siab rau peb cov nqi sib tw thiab kev pabcuam zoo heev.
Hastelloy C276 Txias Rolled Sheet|ASTM B575 UNS N10276|Kev ua tshuaj lom neeg
Hastelloy C276 Sheet (UNS N10276 / 2.4819) yog nickel-chromium-molybdenum-tungsten alloy thiab cov pa roj carbon tsawg thiab silicon. Nws yog nickel-raws li alloy uas muaj kev tiv thaiv corrosion. Raws li lub Hoobkas tsim, peb tsim cov khoom no raws li cov qauv thoob ntiaj teb ASTM B575 thiab ASME SB 575.
Cov qauvKhoom siv: ASTM B575 / ASME SB575
Corrosion Resistance: Resistant pitting, crevice corrosion, thiab kev nyuaj siab corrosion cracking; resistant rau ntub chlorine gas, hypochlorites, thiab chlorine dioxide daws.
Thermal stability: Khaws cov khoom hauv qhov kub ntawm -196℃txog 425 degree.
Thickness:Cold Rolled: 0.3 - 5.0 hli; Kub Rolled: 5.0-80mm
Dav:1000-2500 hli
Ntev:2000-6000mm (Customizable)
Nto tiav: 2B, BA, No.1, No.4, 8K
Mechanical PropertiesLub zog tensile: Ntau dua lossis sib npaug ntawm 690 MPa (Ntau dua lossis sib npaug rau 100 ksi); Yield Strength (0.2% offset): Ntau dua lossis sib npaug rau 283 MPa (Ntau dua lossis sib npaug rau 41 ksi); Elongation (2-inch ntsuas qhov ntev): Ntau dua lossis sib npaug li 40%
Ceev:8.89 g / cm³ (0.321 lb / hauv³)
Melting Point:1370 - 1425 ° (2500 - 2600 ° F)
Fabrication: Haum rau kev sib sau txias, kub sib sau, thiab vuam.
Daim ntawv thov:Kev lag luam tshuaj thiab petrochemical, reactors, kub exchangers, piping, li qub, Flue Gas Desulfurization (FGD) systems, marine thiab offshore ib puag ncig.
Txias -Rolled Hastelloy C276 Nqe Ib Kg
| Hom | Thickness | Nqe (USD / kg) | MOQ |
| Txias-Rolled Sheet | 0.5-1.0 hli | 25–32 | 20 kg ib |
| Txias-Rolled Sheet | 1.0-3.0 hli | 22–28 | 20 kg ib |
| Txias- Rolled Phaj | 3.0-10 hli | 20–25 | 50 kg |
| Txias- Rolled Phaj | 10-30 hli | 18–22 | 50 kg |
Zhengzhou Huitong Pipeline Equipment Co., Ltd. Daim ntawv pov thawj:
✅ ISO 9001: 2015
✅ EN 10204 3.1 Cov ntaub ntawv pov thawj
✅ 100% PMI (Positive Material Identification)
✅ Tsis yog -Kev Ntsuas Kev Ntsuas: Kev Ntsuas Ultrasonic (UT), Kev Ntsuas Tam Sim No (ECT), Kev Ntsuas Hydrostatic
✅ Thib peb-Kev Txhawb Kev Tshawb Fawb: SGS, BV, TÜV
✅ 15 Xyoo ntawm kev paub hauv Exporting Nickel Alloy Tubing
Hastelloy C276 Sheet Material Properties
ASTM B575 UNS N10276 yog ib qho ntawm ob peb alloys resistant rau ntub chloride gas, hypochlorite thiab chlorine dioxide daws.
Hastelloy C276 Chemical Composition
| Qib | C | Mn | Si | P | S | Cr | Mo | Ni | Co | V | W | Fe |
| C276 | Tsawg dua lossis sib npaug li 0.01 | Tsawg dua los yog sib npaug rau 1.0 | Tsawg dua los yog sib npaug li 0.08 | Tsawg dua lossis sib npaug li 0.04 | Tsawg dua los yog sib npaug li 0.03 | 14.5-16.5 | 15.0-17.0 | tshuav nyiaj li cas | Tsawg dua lossis sib npaug li 2.5 | Tsawg dua lossis sib npaug li 0.35 | 3.0-4.5 | 4.0-7.0 |
Alloy C276 Sheet Lub cev muaj zog
| Khoom | Tus nqi |
| Qhov ntom | 8.89 g / cm³ (0.321 lb / hauv³) |
| Melting Range | 1370 - 1425 ° (2500 - 2600 ° F) |
| Modulus ntawm Elasticity | 205 GPa (29.7 × 10³ ksi) |
| Thermal conductivity (20 degree) | 11.2 W/m·K |
| Tshwj xeeb kub muaj peev xwm (20 degree) | 427 J/kg · K |
| Hluav taws xob tiv thaiv (20 degree) | 1.30 μΩ·m |
Nickle Alloy C276 Plate Sheet nto tiav
| No.1 | Kub dov, annealed, nrog oxide nplai, ntxhib nto |
| 2D | Cold dov, annealed, matte tiav, tsis muaj luster |
| 2B | Cold dov, annealed, ci tiav, feem ntau |
| BA | Bright annealed, iav-zoo li luster |
| No.4 | Brushed tiav, unidirectional grain kev ntxhib los mos |
| 8K | Daim iav polished, siab reflectivity |
FAQ:
1. Qhov txawv ntawm qhov txias- dov thiab kub- dov Hastelloy C276 daim ntawv / phaj yog dab tsi?
- Txias- cov ntawv dov muaj qhov ua kom zoo dua qub (2B / BA), qhov siab dua qhov tseeb, thiab cov ntsuas nyias (0.3 - 5.0 mm).
- Kub- dov daim hlau muaj nyob rau hauv cov ntsuas tuab (5.0 - 80 mm) thiab muab cov nqi qis dua.
2. Hastelloy C276 puas tuaj yeem welded yam tsis muaj kev tshaj tawm -weld kev kho cua sov?
Yog lawm. Vim nws cov ntsiab lus tsis tshua muaj carbon tsawg (tsawg dua los yog sib npaug li 0.01%), Hastelloy C276 yog cov resistant rau intergranular corrosion tom qab vuam.
3. Dab tsi yog qhov tsawg kawg nkaus xaj kom muaj nuj nqis (MOQ) rau cov chaw tsim khoom hauv Suav?
Tsis xav tau MOQ. Txawm li cas los xij, rau qhov loj - ntim xaj (Ntau dua lossis sib npaug li 500 kg), koj tuaj yeem ua kom zoo dua ntawm peb cov nqi luv nqi.
4. Lub sij hawm xa khoom ntev npaum li cas rau kev cai C276 daim ntawv / phaj?
Rau cov qauv specifications, lub sij hawm txhuas feem ntau yog 7 mus rau 15 hnub. Rau kev txiav txim, nws yog kwv yees li 15 mus rau 45 hnub.
5. Puas yog Hastelloy C276 tus nqi ntau dua - zoo dua titanium nyob rau hauv ib puag ncig corrosive?
Yog lawm. Txawm hais tias titanium yog kim, Hastelloy C276 qhia tau hais tias kev ua tau zoo tshaj hauv cov tshuaj chloride - muaj thiab acidic ib puag ncig; Tsis tas li ntawd, nws lub neej ua haujlwm ntev heev ua rau nws tus nqi ntau dua - kev xaiv zoo nyob rau lub sijhawm ntev.
Hais txog Zhengzhou Huitong Pipeline Equipment Co., LTD.
HT PIPE yog ib tug zoo-paub stockist thiab exporter. Peb yog cov khoom siv stainless / carbon / npib tsib xee alloy khoom xa khoom nrog 15+ kev xa tawm. Peb tsis tsuas yog muab cov kav dej, phaj, puag ncig, tab sis kuj yog cov yeeb nkab fittings, flanges, thiab lwm yam. Tiv tauj peb kom paub ntau ntxiv thiab cov nqi dawb.
Tus sau: Chloe Pu (5 xyoos hauv stainless hlau, nickel alloy, thiab carbon steel kev lag luam)
Tshaj tawmHnub tim: Lub Plaub Hlis 1, 2026 (Beijing Time)
Cim npe nrov: txias dov hastelloy c276 nickle alloy phaj nqe Hoobkas, Tuam Tshoj, manufacturers, hoobkas, nqe, customized
