ASTM B162 ASME SB162 UNS N02201 Alloy Steel Phaj Sheet
Hom: Phaj, Sheet, Sawb, Coil
Ntev: 0-12m
Dav: 0-2500mm
Thickness: 0.3-1200 hli
Txheej Txheem: Kub / Cold Rolled
Nto: 1,2D,2B,3,4,6,7
Zhengzhou Huitong Pipeline Equipment Co., Ltd. yog ib qho ntawm cov ua lag luam thiab cov neeg muag khoom ntawm astm b162 asme sb162 uns n02201 alloy steel phaj hauv Suav teb. Peb sov siab txais tos koj mus yuav peb astm b162 asme sb162 uns n02201 alloy steel phaj ntawv. Peb lub Hoobkas kuj lees txais cov kev txiav txim customized. Thov pub dawb kom txaus siab rau peb cov nqi sib tw thiab kev pabcuam zoo heev.
ASME SB 162 UNS N02201 Nickel 201 Phaj Sheet Sawb
ASTM B162 UNS N02201 Nickel 201 yog cov pa roj carbon tsawg, cov khoom lag luam ntshiab nickel. Nws ua kom pom qhov ua tau zoo tshwj xeeb hauv kev txo cov kua qaub, alkaline daws, thiab nruab nrab ntsev ib puag ncig.
Qauv:ASTM B162 / ASME SB162Daim ntawv pov thawj: DIN 17750, ISO 6208, BS 3072-3073 (NA12), SAE AMS 5553
Qib:UNS N02201, W.Nr. 2.4068, NA12, Ni 99.2 (LC)
Corrosion Resistance:Siab -kub concentrated alkalis, txo cov kua qaub
Hom:Phaj, Sheet, Sawb / Foil
Qhov ntevThickness: 0.5-100 hli; Dav 1000–2500 mm (max. 3000 mm); Ntev 0-12 m (Customizable)
Khoom Muag Khoom: Annealed, Txias Rolled
Nto tiav: HR, CR, 2B, 2D, BA, Daim iav (Tsis yog{2}}), Satin, thiab lwm yam.
Ceev:8.89 g / cm³
Melting Point Range: 1435 - 1446℃(kwv yees . 2615 - 2635℃F)
Tensile zog:400 - 500 MPa (kwv yees . 58 - 73 ksi)
Yield zog (0.2% Offset):100 - 170 MPa (kwv yees . 15 - 25 ksi); Elongation Ntau dua lossis sib npaug li 40% - 50%; Modulus ntawm Elasticity: kwv yees . 207 GPa (kwv yees . 30,000 ksi)
Kev pabcuam kub: -270℃txog 315℃rau kev siv mus ntev
Daim ntawv thov:Caustic soda (NaOH) evaporators, concentrators, reactors, thiab piping systems; Chlor{0}}alkali kev lag luam khoom siv; Cov nkoj thiab cov cua kub exchangers rau tuav caustic alkalis
Zhengzhou Huitong Pipeline Equipment Co., Ltd. Daim ntawv pov thawj:
✅ ISO 9001: 2015
✅ MTC 10204 3.1 3.2
✅ 100% PMI (Positive Material Identification)
✅ Ultrasonic Testing (Rau ASME VIII)
✅ Kev ntsuas cuam tshuam (feem ntau ntawm -46 degree)
✅ Third-Kev Tshawb Fawb Kev Tshawb Fawb (SGS/BV/DNV/LR)
ASME SB162 UNS N02201 Khoom Khoom:
UNS N02201 Phaj muaj kev tiv thaiv zoo heev rau caustic soda thiab lwm yam alkalis. ASME SB162 Alloy 201 Hlau Phaj ua tau zoo tshaj plaws hauv kev txo cov cheeb tsam, tab sis kuj tuaj yeem siv rau hauv cov xwm txheej oxidizing thaum tsim cov yeeb yaj kiab oxide passive. ASTM B162 Nickel 201 Cov Ntawv yog siv rau hauv aerospace, tshuaj thiab petrochemical ua, ua zaub mov, thiab kev siv dej hiav txwv thiab dej. Nickel 201 Sheets yog ob qho tib si zoo tshaj plaws ntawm qhov kub thiab txias thiab tuaj yeem ua tau yooj yim welded thiab machined los ntawm cov txheej txheem khw fabrication.
Tib lub sijhawm, qib npe ntawm Nickel Alloy 201 Sheet / Phaj kuj yog UNS N022001. UNS N02201 Phaj tsis yog- cov ntawv hlau ferrous suav nrog cov nickel alloys thiab lwm yam khoom ntxiv. ASTM B162 Nickel 201 Phaj txhim kho qhov tshwj xeeb toughness thiab lub zog. Tsis tas li ntawd, Nickel 201 Cold Rolled Phaj nthuav tawm kev ua haujlwm zoo heev hauv cov ntawv thov kub. Cov nickel alloy Werkstoff Nr. 2.4061 thiab 2.4068 daim hlau no tiv taus cov kua qaub thiab tsis cuam tshuam los ntawm lub hauv paus tsis muaj zog ntawm ammonium hydroxide ntawm qhov kub thiab txias. Tsis tas li ntawd, cov boards nthuav tawm cov hauv paus muaj zog rau sodium hydroxide.
NI201 Tshuaj muaj pes tsawg leeg
| Lub ntsiab | Nickel (Ni) | Cov pa roj carbon (C) | Hlau (Fe) | Manganese (Mn) | Silicon (Si) | Copper (Cu) | Sulfur (S) |
| UNS N02201 (Nickel 201) | Ntau dua lossis sib npaug li 99.0% | Tsawg dua lossis sib npaug li 0.02% | Tsawg dua lossis sib npaug li 0.40% | Tsawg dua lossis sib npaug li 0.35% | Tsawg dua lossis sib npaug li 0.35% | Tsawg dua lossis sib npaug li 0.25% | Tsawg dua lossis sib npaug li 0.01% |
ASME SB 162 UNS N02201 Lub cev & Mechanical Properties
| Qhov ntom | 8.89 g / cm³ |
| Melting ntau | 1435 - 1446℃(kwv yees . 2615 - 2635℃F) |
| Tensile zog (annealed) | 400 - 500 MPa (kwv yees . 58 - 73 ksi) |
| Yield zog 0.2% offset (annealed) | 100 - 170 MPa (kwv yees . 15 - 25 ksi) |
| Elongation (ntxiv) | Ntau dua lossis sib npaug li 40% - 50% |
Ntau Txog ASTM B162 Nickel Alloy WNR. 2.4068 Daim Ntawv:
Nickel 200 (UNS N02200) thiab Nickel 201 (UNS N02201) kuj yog cov tshuaj tiv thaiv kom muaj zog, ua lag luam cov ntaub ntawv ntshiab nrog cov khoom siv zoo tshaj plaws ntawm qhov kub thiab txias thiab zoo heev tiv thaiv ntau yam corrosives, tshwj xeeb tshaj yog hydroxides. Nickel 201 yog kev hloov kho ntawm 200 los tswj cov pa roj carbon (.02 max) uas ua kom nws tsis txhob raug embrittled los ntawm intergranular precipitates ntawm qhov kub ntawm 600℃F txog 1400℃F hauv ntau cov txheej txheem. Feem ntau, cov kev txwv ntawm ob qho tib si, AMS 5553 npib tsib xee 200 thiab npib tsib xee 201 Sheets, tau muab tso ua ke rau hauv ib qho, dual{14}} ntawv pov thawj chemistry ua rau ib qho hlau alloy nrog cov yam ntxwv xav tau ntawm ob qho tib si alloys, Nickel 200/201.
Nickel 201 Phaj Sheet Specifications
|
Specification |
ASTM B162 UNS N02201, ASME SB162 |
|
Qhov ntau thiab tsawg |
1000 hli x 2000 hli, 1220 hli x 2440 hli, 1500 hli x 3000 hli, 2000 hli x 2000 hli, 2000 hli x 4000 hli |
|
Thickness |
0.1mm txog 100mm Thk |
|
Dav |
10-2500 hli |
|
Ntev |
2m, 2.44m, 3m, lossis raws li xav tau |
|
Ua kom tiav |
Kub dov phaj (HR), Cold Rolled Sheet (CR), 2B, 2D, BA NO (8), SATIN (Met with Plastic Coated) |
|
Hardness |
Mos, Hard, Ib nrab Hard, Quarter Hard, Spring Hard thiab lwm yam. |
|
Tshuag hauv daim ntawv ntawm |
Phaj, Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Phaj, Rolling Sheet, Flat Sheet, Rolling Plate, Flat Shim, Blank (Valk), kub dov, txias dov, annealed, mos annealed, descaled, sheared, tread phaj, check |
|
Khoom siv |
JIS: N0, N2, N1, NW2200, NW2201, NW4400, NW5500, NW6002, thiab lwm yam |
|
ASTM Txuj |
ASTM A162, GB / T2054, DIN177502002, ASTM B127, ASTM B435, ASTM B582, ASTM B575, ASTM B168, ASTM B443, ASTM B463, ASTM B626, ASTM B536 thiab lwm yam |
|
Vim li cas thiaj xaiv HT PIPE? |
|
|
Nickel 201 profiles |
Txhawm rau muab cov kev pabcuam profileing tag nrho peb siv ntau txoj hauv kev profile suav nrog:
|
Nickel 201 phaj
Thickness: 6mm - 100mmSurface: Kub dov, pickled, polished
Nickel 201 daim ntawv
Thickness: 0.8mm-6.0mmSurface: 2B, BA, polished
Nickel 201 sawb
Thickness: 0.1mm-1.0mm Dav: 10mm-600mm
ASME SB162 UNS N02201 Alloy Steel Phaj Sheet, ASTM B162 Nickel 201 Sheets Exporter, Nickel 201 Phaj, Nickel 201 Cold Rolled Phaj, Nickel Alloy WNR. 2.4068 Sheets Strips Chaw tsim tshuaj paus
Kev txwv kev siv rau Annealed Stainless hlau 201
Nickel 201 tsis yog cov khoom siv thoob ntiaj teb. Nws nthuav tawm tus nqi corrosion sai heev hauv oxidizing acids -xws li concentrated nitric acid lossis aerated acids siab heev - thiab yog li tsis tsim nyog rau kev siv hauv cov kev pabcuam zoo li no.
FAQ:
1. Dab tsi yog qhov txawv ntawm Nickel 201 thiab Nickel 200?
Qhov sib txawv yog nyob rau hauv lawv cov ntsiab lus carbon. Cov ntsiab lus siab tshaj plaws rau Nickel 200 yog 0.15%, thaum rau Nickel 201, nws tsuas yog txwv rau 0.02%. Tsis zoo li Nickel 200- uas dhau los ua nkig-Nickel 201 tsis raug kev txom nyem los ntawm graphitization embrittlement thaum raug rau lub sijhawm ntev ntawm qhov kub siab tshaj 315℃.
2. Kwv yees li pes tsawg tus nqi Nickel 201?
Nickel 201 phaj nqi feem ntau yog li ntawm $ 40 txog $ 50 ib kilogram, sib txawv raws li tej yam xws li thickness, dav, tus neeg muag khoom, thiab kev lag luam hloov pauv.
3. Kuv cov cuab yeej siv rau qhov evaporative concentration ntawm caustic soda (NaOH) thiab ua haujlwm ntawm qhov kub ntawm 350 degree; Kuv puas yuav tsum xaiv Nickel 200 lossis Nickel 201?
Koj yuav tsum xaiv Nickel 201. Nickel 200 yog qhov cuam tshuam rau graphitization embrittlement thaum raug rau ncua sij hawm ntawm qhov kub siab tshaj 315℃.
4. Puas yog Nickel 201 sib nqus?
Nickel 201 muaj tsawg sib nqus permeability thiab yog ze li ntawm tsis yog -magnetic nyob rau hauv ib txwm kub, ua rau nws zoo tagnrho rau precision instruments.
5. Puas yog Nickel 201 tuaj yeem siv rau hauv dej hiav txwv?
Nws muaj qee qhov kev tiv thaiv tab sis tsis zoo. Nws ua tau zoo dua hauv kev txo qis thiab alkaline ib puag ncig dua li hauv dej hiav txwv.
6. Dab tsi yog qhov kev kho cua sov rau Nickel 201 daim ntawv?
Annealing ntawm 700-900 degree, ces txias ceev kom rov qab ductility.
7. Puas yog Nickel 201 haum rau kev pab cuam caustic soda?
Yog lawm, nws yog ib qho ntawm cov ntaub ntawv zoo tshaj plaws rau siab - kub thiab siab - concentration sodium hydroxide ib puag ncig.
8. Puas yog Nickel 201 corrosion- tiv taus hydrochloric acid?
Nws ua tau zoo hauv dilute HCl tab sis tsis pom zoo rau cov concentrated lossis kub hydrochloric acid.
Q: Txog nickel 201 tus nqi?
Q: Koj lub sijhawm khoom xa tuaj ntev npaum li cas?
Q: Puas muaj Kev Pabcuam Qauv?
Q: Yam tsawg kawg nkaus Order Quantity yog dab tsi?
Q: Yuav ntim cov khoom li cas?
Q: Lub teb chaws xa tawm
Q: Peb puas tuaj yeem tuaj xyuas koj lub Hoobkas?
A: Tau kawg, koj ib txwm txais tos!
Q: Puas yog nws zoo rau kos kuv lub logo ntawm cov khoom?
A: Yog. Peb yog OEM thiab ODM, Kev them nyiaj yug Customized
