AL6XN phaj
Hom: Phaj, Sheet, Sawb, Coil
Ntev: 0-12m
Dav: 0-2500mm
Thickness: 0 3-1200 hli
Txheej Txheem: Kub / Cold Rolled
Nto: 1,2D,2B,3,4,6,7
AL6XN Phaj, AL6XN Stainless Hlau Phaj, AL6XN Stainless Hlau Sheet, N08367 Chev, AL6XN Kub Rolled Phaj, AL6XN Cold Rolled Phaj.
AL6XN phaj (UNS N08367) yog "super austenitic" qis carbon stainless hlau. AL6XN Stainless Hlau Phaj muaj 6.3% molybdenum. Hauv kev sib piv, koj yuav pom tias AL6XN dov daim ntawv yog 50% muaj zog dua stainless hlau yeeb nkab. Meanwhile, AL6XN daim ntawv yog ruaj khov ntawm 1000 degree F. AL6XN Flat Gaskets muaj corrosion kuj zoo heev rau oxidizing ib puag ncig, ntau yam acids, bases, ntsev tov, dej hiav txwv, crevices, kev nyuaj siab thiab tag nrho cov corrosion.
Lub zog siab thiab corrosion tsis kam ntawm AL6XN alloys ua rau AL6XN Daim Hlau yog qhov kev xaiv zoo dua li cov khoom siv duplex stainless hlau thiab tus nqi tsim nyog rau cov khoom kim heev npib tsib xee-raws li alloys, uas muaj cov formability zoo heev, weldability, lub zog thiab corrosion kuj. Tsis tas li ntawd, cov ntsiab lus chromium, molybdenum, thiab nitrogen hauv AL6XNStainless hlau phajtag nrho cov kev pab muab kev tiv thaiv rau acidic oxidizing chloride daws yav tas los tsuas yog ua tiav nrog npib tsib xee-raws li alloys. Cov nickel siab (24%) thiab molybdenum (6.3%) cov ntsiab lus ua rau N08367 Coil ib qho kev daws teeb meem rau chloride ion kev ntxhov siab corrosion tawg.
Product Description
Tshuaj muaj pes tsawg leeg,%
|
Ni |
Cr |
Mo |
C |
N |
Mn |
Si |
P |
S |
Cu |
Fe |
|
23.5-25.5 |
20.00-22.00 |
6.00-7.00 |
0.03 Max |
0.18-0.25 |
2 0 Max |
1. 00 Max |
.040 Max |
0.03 Max |
0.75 Max |
Tseem tshuav |
ASTM Cov Lus Qhia
|
Cov yeeb nkab Welded |
Tube Welded |
Ntawv / phaj |
Bar |
Flanges & Fittings |
|
B675, A312 |
B676, A249 |
B688, A240 |
B691, A479 |
B462, A182 |
Mechanical Properties
Sawv cev Tensile thiab Impact Properties, Phaj
|
Temp. Qib F (degree) |
Ult. Tensile zog, psi |
.2% Yield zog, psi |
Elongation hauv 2", feem pua |
Charpy V-Notch Toughness, ft-lb |
|
-450 (-268) |
218,000 |
142,000 |
36 |
353* |
|
-320 (-196) |
196,000 |
107,000 |
49 |
85 |
|
-200 (-129) |
- |
- |
- |
100 |
|
70 (21) |
108,000 |
53,000 |
47 |
140 |
|
200 (93) |
99,900 |
49,400 |
47 |
- |
|
400 (204) |
903,000 |
40,400 |
46 |
- |
|
600 (316) |
86,000 |
36,300 |
47 |
- |
|
800 (427) |
87,000 |
36,000 |
48 |
- |
