ASTM A 479 309 Phaj
Hom: Phaj, Sheet, Sawb, Coil
Ntev: 0-12m
Dav: 0-2500mm
Thickness: 0 3-1200 hli
Txheej Txheem: Kub / Cold Rolled
Nto: 1,2D,2B,3,4,6,7
ASTM A479 309 Phaj, SS 309 Phaj, Stainless Hlau SUS 309 Kub Rolled Phaj, Stainless Hlau 309 2B Finish Phaj, ASME SA240 Stainless Steel 309 Phaj, ASTM A240 SS 309 Phaj, AISI SS 309 Phaj .
ASTM A479 309 Phaj yog cov hlau alloy siab uas muaj kev tiv thaiv corrosion zoo li piv rau lwm cov hlau vim tias muaj cov chromium loj heev. Raws li cov qauv crystalline, SS muab faib ua ferritic, martensitic thiab austenitic steel. SS 309 Phaj muaj kev tiv thaiv corrosion siab thiab lub zog piv rau lwm qib ntawm SS alloy. Stainless Hlau SUS 309 Kub Rolled Phaj tuaj yeem ua tau yooj yim thiab tuaj yeem ua tau yooj yim welded los ntawm kev tsis kam vuam txoj kev thiab fusion. Nws yog kub ua haujlwm ntawm 2150 Deg F thiab tuaj yeem ua kom nrawm dua. Yog li niaj hnub no Stainless Hlau 309 2B Finish Phaj siab nyob rau hauv kev thov ntawm ntau yam lag luam.
ASTM A479 309 Phaj yog ua los ntawm austenitic stainless hlau uas feem ntau siv rau kev siv kub siab. Vim muaj cov ntsiab lus chromium thiab npib tsib xee muab piv rau superior tiv thaiv oxidation thiab corrosion kuj. Zoo ib yam li 304, ASME SA240 Stainless Hlau 309 Phaj kuj tuaj yeem ua tshuab. Los ntawm kev siv txoj kev tiv thaiv thiab fusion, ASTM A240 SS 309 Phaj kuj tuaj yeem welded. Rau vuam 347H stainless hlau oxyacetylene vuam tsis pom zoo.
SS 309 Plate Chemical Composition
| Qib | Fe | Cr | Ni | Mn | Si | C | P | S |
| SIB 309 | 60% | 23% | 14% | 2% | 1% | 0.20% | 0.045% | 0.030% |
ASTM A240 TP 309 Stainless Hlau Sheets Lub cev & Mechanical Properties
| Yield zog {{0}}.2% Offset0 |
Qhov kawg Tensile Lub zog |
Elongation ua 2in. |
Hardness | ||
| psi (min.) | (MPa) | psi (min.) | (MPa) | % (min.) | (max.) |
| 45,000 | 310 | 85,000 | 586 | 50 | 202 (HBN) |
Cim npe nrov: astm a479 309 phaj, Suav teb, manufacturers, hoobkas, nqe, customized
