ASTM B435 Hastelloy X Phaj

Hom: Phaj, Sheet, Sawb, Coil
Ntev: 0-12m
Dav: 0-2500mm
Thickness: 0.3-1200 hli
Txheej Txheem: Kub / Cold Rolled
Nto: 1,2D,2B,3,4,6,7

Xa kev nug

Hastelloy X Phaj piav qhia

Hastelloy X Phaj yog qhov kub thiab txias thiab corrosion resistant npib tsib xee-raws li cov khoom siv ntxiv zog alloy phaj. Nickel X Sheet muaj qhov ua tau zoo rau oxidation thiab muaj lub zog tshwj xeeb ntawm qhov kub siab. Molybdenum ua rau Alloy X phaj ua kom tawv, muaj zog, thiab tsim nyog rau kev siv vuam. ASTM B435 Hastelloy X Phaj nthuav tawm zoo formability thiab machinability.

Factory ASTM B435 UNS N06002 Phaj, Hastelloy X Cov Khoom Muag Khoom Muag, Kub Rolled (HR) Daim Hlau, Cov Ntawv Txias Rolled, Tiv tauj peb kom tau txais daim ntawv teev nqi, Customized Size & Free Sample!

hastelloy x cov khoom siv

UNS N06002 Phaj tsis yog{1}}magnetic. Nws muaj lub zog siab txog 1200℃(2200℃F) thiab zoo oxidation tsis kam mus txog 1175℃(2150℃F). Hastelloy Alloy X Kub Rolled (HR) Sheet yog tshwj xeeb tshaj yog resistant rau carburization thiab nitriding, tej yam kev mob uas ua rau tsis ua hauj lwm nyob rau hauv ib co kub alloys. Hastelloy X Phaj yog siv dav hauv kev kub siab dav hlau cav thiab kev siv tshuaj lom neeg thiab muaj kev tiv thaiv zoo rau kev ntxhov siab corrosion tawg hauv kev siv petrochemical. Kev siv hluav taws xob muaj kev sib koom ua keHastelloy Steel Phajrau nws cov tsis kam mus oxidizing thiab nws muaj peev xwm tswj tau zoo ductility tom qab ntev raug rau kub heev.

ASTM B435 Hast x Alloy Phaj Specification

Specification	ASTM B435 ASME SB 435
Qhov ntau thiab tsawg	1000 hli x 2000 hli, 1220 hli x 2440 hli, 1500 hli x 3000 hli, 2000 hli x 2000 hli, 2000 hli x 4000 hli
Thickness	0.1mm txog 100mm Thk
Dav	10-2500 hli
Ntev	2m, 2.44m, 3m, lossis raws li xav tau
ASTM	ASTM B168
Ua kom tiav	Kub dov phaj (HR), Cold Rolled Sheet (CR), 2B, 2D, BA NO (8), SATIN (Met with Plastic Coated)
Hardness	Mos, Hard, Ib nrab Hard, Quarter Hard, Spring Hard thiab lwm yam.
Tshuag hauv daim ntawv ntawm	Phaj, Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Sawb, Flats, Clad Phaj

Hu rau tam sim no

Tshuaj muaj pes tsawg leeg ntawm Hastelloy Alloy X Sheet & Phaj

Qib	C	Mn	Si	Al	Co	Ni	Cr	Fe	Mo	Ti
Hastelloy X	0.05-0.15	1.0 max	1.0 max	0.50 max	0.5-2.5	Tseem tshuav	20.5 - 23	17 - 20	8 - 10	0.15 max

Mechanical Properties ntawm Hastelloy X Sheet & Phaj

Qhov ntom	Melting Point	Tensile zog	Yield zog (0.2% Offset)	Elongation
8.22 g / cm3	1355℃(2470℃F)	95 KSI min (655 MPa min)	35 KSI min (240 MPa min)	35 %

Astm b435 Hastelloy X Plate

ASTM B435 Txuj

ASTM B435 npog UNS N06002 (Hastelloy X) phaj, ntawv thiab sawb rau kev siv kub. Peb cov chaw tsim khoom tsim cov khoom siv Hast x rau cov qauv nruj rau cov tshuaj muaj pes tsawg leeg. Muab nyob rau hauv cov mob annealed nrog ib daim ntawv ntsuam xyuas zeb (MTR / ntawv pov thawj) rau tshuaj muaj pes tsawg leeg thiab txhua yam khoom.

Peb muab haynes hastelloy x:

EN 10204/3.1B,
Raw Materials Certificate
100% Kev Tshawb Fawb Kev Tshawb Fawb Txog Kev Tshawb Fawb
ISO9001, CE certification, SGS, BV thib peb-kev xeem
Cov kev pabcuam customized

Factory hastelloy x Kev kho cua sov:

Feem ntau daws cov cua sov-kho ntawm 2150℃F (1177 degree) thiab txias sai.

Cov ntawv thov rau Hastelloy X Phaj:

Combustion Chambers rau roj turbine xyaw (aerospace thiab industrial)
Combustion liners rau industrial furnaces thiab cua sov.
Thaum tshav kub kub kho jigs thiab pallets
Petrochemical processing Cheebtsam (piv txwv li, cov khoom siv hluav taws xob, hluav taws xob hluav taws xob).

FAQ

Q: Hais txog Hastelloy x nqe?

A: Nqe los ntawm ntau yam $ 22 - $ 35 USD / kg, txawv nyob ntawm qhov loj me, phab ntsa thickness, tus neeg muag khoom thiab lwm yam.

Q: Koj lub sijhawm khoom xa tuaj ntev npaum li cas?

A: Lub sij hawm xa tuaj yog nyob rau hauv 5-21 hnub

Q: Puas muaj Kev Pabcuam Qauv?

A: Cov qauv raug muab pub dawb

Q: Yam tsawg kawg nkaus Order Quantity yog dab tsi?

A: Tsis muaj qhov txiav txim yam tsawg kawg nkaus

Q: Yuav ntim cov khoom li cas?

A: Cov txheej sab hauv muaj cov ntawv tsis muaj dej tsis zoo sab nrauv thiab kho nrog fumigation ntoo pallet.

Q: Lub teb chaws xa tawm

A: Brazil, South Africa, Indonesia, Is Nrias teb, Singapore, Malaysia, Iran, Russia, UAE, Chile, Laos, thiab lwm yam

Q: Peb puas tuaj yeem tuaj xyuas koj lub Hoobkas?

A: Tau kawg, koj ib txwm txais tos!

Q: Puas yog nws zoo rau kos kuv lub logo ntawm cov khoom?

A: Yog. Peb yog OEM thiab ODM, Kev them nyiaj yug Customized
