UNS N06030 G30 W.NR 2.4603 AWS 056 Hot Rolled Plate Sheet
Hom: Phaj, Sheet, Sawb, Coil
Ntev: 0-12m
Dav: 0-2500mm
Thickness: 0 3-1200 hli
Txheej Txheem: Kub / Cold Rolled
Nto: 1,2D,2B,3,4,6,7
UNS N06030 G30 W.NR 2.4603 AWS 056 Hot Rolled Plate Sheet
Hastelloy G-30 yog cov khoom siv nickel-chromium-hlau alloy. UNS N06030 Phaj yog ib qho kev txhim kho ntawm Hastelloy G3. UNS N06030 Phaj muaj cov ntsiab lus chromium ntau dua, yog li W.NR 2.4603 Phaj muaj corrosion kuj rau oxidizing acids xws li nitric acid thiab chloric acid. Hastelloy G-30 Phaj muaj cov ntsiab lus tooj liab thiab molybdenum ntau heev. Nws kuj muaj qee yam tsis kam txo cov kua qaub xws li sulfuric acid thiab hydrochloric acid.
Tshwj xeeb, UNS N06030 Phaj yog tsim nyog hais tias Hastelloy G30 muaj cov qib siab ntawm kev tiv thaiv "cov txheej txheem ntub dej" phosphoric acid. "Cov txheej txheem ntub dej" phosphoric acid (P 2 O 5) yog tsim los ntawm phosphate pob zeb thiab sulfuric acid cov tshuaj tiv thaiv, uas yog agrochemical chiv. Lub hauv paus tseem ceeb ntawm phosphorus, Hastelloy G-30 Phaj yog dav siv nyob rau hauv kev lag luam chiv. HASTELLOY G-30 yog ib qho nyuaj tshaj li austenite thiab yeej zoo ib yam li lwm cov alloys nyob rau hauv cov nqe lus ntawm formability. W.NR 2.4603 Phaj muaj ductility zoo thiab ua haujlwm txias yog txoj kev nyiam tshaj plaws. Cov hlau feem ntau yog welded siv cov roj hlau arc, roj tungsten arc, thiab shielded hlau arc.
Tshuaj muaj pes tsawg leeg
|
Element |
Cov ntsiab lus (%) |
|
Nickel, Nia |
43 |
|
Chromium, Cr |
28.0-31.5 |
|
Hlau, Fe |
13-17 |
|
Cobalt, Co |
5 |
|
Molybdenum, Mo |
4-6 |
|
Tungsten, W |
1.50 - 4 |
|
Manganese, Mn |
1.50 |
|
tooj, Cu |
1 - 2 .40 |
|
Silicon, Sib |
0.8 |
|
Phosphorus, P |
0.040 |
|
Carbon, C |
0.030 |
|
Sulfur, S |
0.020 |
Lub cev muaj zog
|
Cov khoom |
Metric |
Imperial |
|
Qhov ntom |
8.22 g / cm³ |
0.297 lb/in³ |
|
Melting point |
1371ºC |
2500ºF |
Mechanical Properties
|
Cov khoom |
Metric |
Imperial |
|
Tensile zog |
1096 MPa rau |
159 000 psi |
|
Yield strength (@0.2 percent ) |
1000 MPa |
145 000 psi |
|
Modulus ntawm elasticity (phaj kub kho rau 1177 degree, ceev quenched) |
202 GPA |
29 300 tzs |
|
Elongation ntawm tawg (hauv 50.8 hli) |
12 feem pua |
12 feem pua |
|
Kev txo qis ntawm cheeb tsam |
57 feem pua |
57 feem pua |
|
Hardness, Brinell (hloov los ntawm Rockwell C hardness) |
304 |
304 |
|
Hardness, Knoop (hloov los ntawm Rockwell C hardness) |
326 |
326 |
|
Hardness, Rockwell C |
32 |
32 |
|
Hardness, Vickers (hloov los ntawm Rockwell C hardness) |
316 |
316 |
Thermal Properties
|
Cov khoom |
Metric |
Imperial |
|
Thermal expansion co-efficient (@30-316ºC/86-601ºF) |
14.4 µm / m degree |
8 µin / hauv degree F |
|
Thermal conductivity |
10.2 W / mK |
70.8 BTU in/hr.ft2. degree F |
