Tom ntej: Incoloy 825 Flange

Hom: SO, SW, BL, BL, WN, LJ, Spectacle, Orifice ect.
Loj: 1/2" -48", DN 10-DN4000
Chav Kawm: 75#-2500#, PN6-PN100
Txuj: ASME, DIN, EN, JIS, BS

Incoloy UNS N08825 Yeeb Nkab Flanges, Inconel 825 Nippolet Flanges, Incoloy 825 Slip On Flanges, Inconel 825 Ntev weld caj dab, Incoloy DIN 2.4858 Socket Weld Flanges, ASTM B564 Incoloy 825 RTJ Flange

Incoloy 825 Yeeb Nkab Flanges Specifications
Specifications	:	ASTM B564 / ASME SB564
Loj	:	1/2 "NB TO 60" NB
Cov qauv	:	ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, thiab lwm yam.
Chav kawm / Siab	:	150 #, 300 #, 600 #, 900 #, 1500 #, 2500 #, PN6, PN10, PN16, PN25, PN40, PN64 thiab lwm yam.
Txuj	:	ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, thiab lwm yam.

Incoloy Alloy 825 Yeeb Nkab Flanges Chemical Composition

Qib	C	Mn	Si	S	Cu	Fe	Ni	Cr	Al	Ti
825	0.05 max	1 00 max	0.5 max	0.03 max	1.50 – 3.00	22.00 feeb	38.00 – 46.00	19.50 – 23.50	0.02 max	0.06 – 1.20

Incoloy 825 Phaj Flanges Mechanical Properties

Lub ntsiab	Qhov ntom	Melting Point	Tensile zog	Yield Strength (0.2 feem pua Offset)	Elongation
825	8.14 g / cm3	1400 degree (2550 degree F)	Psi – 80, 000, MPa – 550	Psi – 32, 000, MPa – 220	30 feem pua

Qib sib npaug rau 825 Incoloy Industrial Pipe Flanges

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN	LOSSIS
lus 825	2.4858	N08825	SIB 825	NA 16	ЭП703	NFE30C20DUM	NiCr21Mo	XH38BT

Cim npe nrov: Incoloy 825 Flange, Suav teb, manufacturers, hoobkas, nqe, customized
